1.Rated temperature : 80℃ 90℃ 105℃ 1.额定温度：80℃ 90℃ 105℃
2.Rated voltage : 1000V 2.额定电压：1000V
3.Solid or Stranded,tinned or bare copper 3.导体使用单根或绞合30-2000 kcmil 镀锡或
conductor 30-2000 kcmil 裸铜线
4.PVC insulation 4.绝缘采用聚氯乙烯材料
5.Passes UL VW-1&CSA FT1 Vertical 5.通过UL VW-1及CSA FT1 垂直燃烧
flame test 6.绝缘厚度均匀，易剥。易裁
6.Uniform insulation thickness of wire to 7.环保要求：符合ROHS标准
ensure easy stripping and cutting 8.产品广泛用于一般电子，电器设备内部连线
7.Environmental tesing pass ROHS
8.Ground strap lead wire for the internal
wiring of electronic equipment
